HARDWARE FEATURES
Efficiency: 90% ~ 93%
OUTPUT
Transfer Time: 10 ms (for personal computers) 20 ms (for home appliances)
TECHNICAL SPECIFICATION
Battery Voltage: 48 VDC
Rated Power: 6000VA/6000W
Surge Power: 12000VA
GENERAL SPECIFICATION
Frequency Range: 50 HZ / 60 HZ (Auto sensing)
Net Weight: 12 kg
Operating Temperature: -10’C to 50’C
Voltage: 230 VAC
Wave form: Pure sine wave
Dimension: 119 x 313.6 x 457.5
The Power Square Sunwoda 51.2V Lithium Battery is a high-performance energy storage solution designed for modern solar systems. Built with advanced lithium technology, it delivers stable power output, long lifespan, and superior efficiency for both residential and commercial applications.
This battery ensures reliable backup power, fast charging capability, and deep cycle performance, making it ideal for solar hybrid systems and off-grid installations. Its smart BMS (Battery Management System) provides complete protection against overcharging, overheating, and deep discharge, ensuring maximum safety and durability.
With its compact design and high energy density, the Sunwoda lithium battery is a perfect replacement for traditional lead-acid batteries, offering better efficiency, lower maintenance, and longer service life.
SUNWODA 51.2V LITHIUM BATTERY DATA SHEET (PDF) INSTALLATION GUIDE / MANUAL
| Parameter | Specification |
| Brand | Power Square Solar Energy |
| Battery Type | Lithium Iron Phosphate (LiFePO4) |
| Nominal Voltage | 24V |
| Capacity | 100Ah (2.4 kWh total energy storage) |
| Life Cycles | Up to 6000 Cycles @ 80% DOD |
| Smart Features | Wi-Fi Connectivity & Status LCD Screen |
| Cooling/Safety | Built-in Smart BMS Protection |
MPPT Power increase to 3kW.
Charging current increase to 80A.
Selectable input voltage range for home appliances and personal computers.
Configurable AC/Solar input priority via LCD setting.
Compatible to main voltage or generator power.
Cold start function.
Works without battery.
Smart battery charge design for optimized battery performance.
Dual output for smart load management.
Maximum PV input current.
Wide PV input voltage Range 60VDC~450VDC.
Customizable status LED ring with RGB lights.
Battery independent design.
Enhanced charging power.
Support USB on the GO-THE-GO function.
Touchable button with large 4.3" colored LED.
Built-in Wifi for mobile monitoring (Android/iOS App available).
Built-in anti-dust kit.
Data log event stored in the inverter.
Reserved communication port (RS485, CAN-BUS or RS232) for BMS.
Battery equalization extends life cycle.
Maximum PV input current 27A.
Dual output for smart load management.
Touchable button with 4.3" colored LED.
Self-consumption and feed into grid.
Programable supply priority for PV. battery or grid.
User-adjustable charging current and voltage.
Programable multiple operations mode: Grid-tie, off-grid and grid-tie with backup.
Built-in Wifi or mobile monitoring (App is available).
Reserved communication port for BMS.
Parallel operation up to 9 units.
